- THÔNG TIN CHI TIẾT SẢN PHẨM
- THÔNG SỐ KỸ THUẬT
| odel |
CPR02 |
| Features |
Date, time, statistic and totalization functions |
| Printer |
Dot Matrix Printer |
| No. of characters per line |
24 Character |
| Printing Speed |
Faster than 1 line per second |
| Paper Type |
Normal paper roll, wood free paper |
| Paper Size |
Width: 57.5 ± 0.5mm, Core Diameter : 8mm Min. |
| Power Supply |
AC Input 100V - 270VAC & 50Hz - 60Hz |
| Interface |
RS 232 C |
| Baud Rate |
1200, 2400, 4800, 9600, 19200 |
| Parity |
None, Space, odd,even |
| Data Bit |
8 bit |
| Stop Bit |
1 |
| Working Temperature |
5˚C to 50˚C; Relative Humidity: 10% to 80% No condensation |
| Dimension(mm/inch) (LxWxH) |
210x135x88.5/ 8.30'x5.30'x3.50' |
| Net Weight/ Gross Weight |
2.00 kgs/ 2.00 kgs |
| Packing Size(mm/ inch) |
270x200x175/ 10.62'x7.8'x6.90' |
| Components |
9 pin Rs232 Cable, 13V DC Adapter, Ink Ribbon
Paper Roll, user manual and warranty |
